Products Description
| Item No. | LNA-180 | LNA-220 | LNB-250 | LNC-300 |
LN-120 (Portable) |
| Air Flow | 18000 m³ | 22000 m³ | 25000 m³ | 30000 m³ | 12000 m³ |
| Power Supply | 380V/220V | 380V/220V | 380V | 380V | 220V |
| Working Current | 2.7/4.8(A) | 3.4(A) | 4.5(A) | 5.8(A) | / |
| Frequency | 50HZ | 50HZ | 50HZ | 50HZ | 50HZ |
| Power Consumption | 1.1kw | 1.5kw | 2.2kw | 3.0kw | / |
| Water Consumption | 5-10(L/h) | 10-15(L/h) | 10-15(L/h) | 40(L/h) | 8-10(L/h) |
| Water Tank Capacity | 25L | 25L | 25L | 40L | 50L |
| Air Out Dimension | 670x670mm | 670x670mm | 670x670mm | 800x800mm | / |
| Physical Dimension | 1100x1100x950mm | 1100x1100x950mm | 1100x1100x1150mm | 1280x1280x1250mm | / |
| Net Weight | 55 kgs | 57kgs | 65kgs | 120kgs | 43kg |
| Fan Type | Axis-flow | Axis-flow | Axis-flow | Axis-flow | Axial |
| Effective Area | 90-120m² | 100-150m² | 150-200m² | 200-250m² | / |
Main Component
Component
Working Principle
Industrial Cooling
Rapid cooling, high work efficiency
Pure Copper Motor
Quality motor creates strong wind effect
Double Filtration
Thickened wet curtain, double fresh filtration
Fan Blade
Large wind pressure and sufficient air volume
Shell
Thicker panel, stable and reliable quality, kept from aging, UV and rust with a lifetime
Filter Pump
Filtering water impurities, stable performance, less prone to failure
Louver
High density, better water absorption and increase the cooling effect
Drain Valve
100% complete draining
Float Ball Valve
When the water arrive float level, it will stop pumping work
Loading
