Products show
DH direct fired fan heater
DH25PV indirect fired heater
DHC40 heater
Mirage indirect heater
ST100
Tornado direct fired fan heater
Helios indirect output heater
Products Specification
| Item No. | DH-20 | DH-40 |
| Heat Output | 23KW | 43KW |
| KCal/h | 20000 | 37000 |
| Btu/h | 78000 | 148000 |
| Air output | 400m³/h | 1050m³/h |
| Motor | 100w | 250w |
| Oil Consumption | 1.8L/h | 3.5L/h |
| Tank capacity | 21L | 42L |
| Electrical supply | 230V-50Hz | 230V-50Hz |
| Weight | 26kg | 37kg |
| Size(mm) | 810*360*380 | 930*440*570 |
DH havs longer life compared with other competitors. Ideal for drying in building sites and heating well ventilated small or medium premises. There are two types you can choose. So over the years DH has always been one of the most popular products.
| Item No. | DH25PV |
| Heat output | 26KW |
| KCal/h | 22400 |
| Btu/h | 88700 |
| Air output | 800m³/h |
| Motor | 300w |
| Oil Consumption | 2L/h |
| Tank capacity | 42L |
| Electrical supply | 230V-50Hz |
| Size(mm) | 950*520*570 |
DH25PV is ideal for heating or drying in closed premises. Heat exchanger to keep exhaust gas and hot air separate. Functions on oil or paraffin.
| Item No. | DHC40 |
| KCal/h | 30100 |
| Air output | 1000m³/h |
| Fan power | 80W |
| Oil Consumption | 3.5L/h |
| Electrical supply | 220V-50Hz |
| Motor | 30w |
| Weight | 40kg |
| Tank capacity | 50L |
| Size(mm) | 890*560*830 |
| Item No. | Mirage 37 | Mirage 55 | Mirage 85 |
| Heat output(max) | 36.4 kw/h | 52.5kw/h | 83.9kw/h |
| 31300cal/h | 45200cal/h | 72200cal/h | |
| Air velocity | 2500m³/h | 3000m³/h | 5500m³/h |
| Fuel consumption | 3.35L/h | 4.84L/h | 7.72L/h |
| Power supply | 220V-50Hz | 220V-50Hz | 220V-50Hz |
| Power of main fan | 370 w | 370 w | 550w |
| Power of burner fan | 150 w | 150 w | 150 w |
| Unit weight | 76kg | 91kg | 147kg |
| Size(mm) | 1180*460*960 | 1410*460*960 | 1720*720*1060 |
ST100
| Item No. | ST100 |
| KCal/h | 78260KCal/h |
| Air output | 1900m³/h |
| Motor | 250w |
| Oil Consumption | 9.1L/h |
| Electrical supply | 220V-50Hz |
| Output power | 91KW |
| Air pump pressure | Imported gear pump |
| Size(mm) | 1400*620*790 |
Tornado direct fired fan heater
| Item No. | Tornado 67 | Tornado 115 |
| Heat output(max) | 66kw/h | 115kw/h |
| 56700 cal/h | 99100 cal/h | |
| Air velocity | 3000m³/h | 5000m³/h |
| Fuel consumption | 6.07m³/h | 10.6m³/h |
| Power supply | 220V-50Hz | 220V-50Hz |
| Power of main fan | 370 w | 500 w |
| Power of burner fan | 150 w | 150 w |
| Unit weight | 83kg | 130kg |
| Size(mm) | 1410*460*960 | 1720*720*1060 |
| Model | Helios140 | Helios170 | Helios150C | Helios200C |
| Heat output (kcal/h) | 120.4 | 149.2 | 124.7 | 166.7 |
| Heat output (Btu/h) | 477747 | 592026 | 494810 | 661466 |
| Heat output (kw) | 140 | 174 | 145 | 195 |
| Efficiency(%) | 89.7 | 90.3 | 90.3 | 90.3 |
| Air output (m³/h) | 11000 | 14000 | 11000 | 14000 |
| Air pressure(mmH20) | 9 | 9 | 52 | 53 |
| Absorbed power(W) | 2300 | 3100 | 2300 | 3100 |
| Voltage (V/Hz) | 230/50 | 400/50 | 400/50 | 400/50 |
| Weight ( kg) | 235 | 330 | 295 | 400 |
| Stack Dia(mm) | 200 | 250 | 200 | 250 |
| Air Outlet Dia(mm) | 520 | 690 | 520 | 690 |
| Size(mm) |
1945×840 ×1420 |
2445×1055 ×1670 |
2120×840 ×1420 |
2655×1065 ×1670 |
