Product Introduction

Redefining efficient cleaning of farms

Cleaning livestock pens has always been a key bottleneck restricting the improvement of breeding efficiency. Problems such as the time-consuming and labor-intensive nature of manual cleaning, incomplete cleaning of hard-to-reach areas, inefficient water use, and the potential for disease prevention and safety hazards related to personnel handling manure directly impact the healthy growth of livestock and the overall profitability of breeding.

This intelligent cleaning robot for livestock farms is a highly efficient and intelligent cleaning device developed for large-scale breeding scenarios. It integrates intelligent path planning technology, a precise spray control system, and a remote control module, adaptable to the pen structures and cage layouts of different types of farms.

The equipment is easy to install, requiring no complex modifications; simply connecting to the water supply pipes is sufficient for operation. By pre-setting cleaning programs via remote control or smart terminal, it can perform comprehensive and thorough cleaning of key areas such as pen ceilings, cage gaps, feeding troughs, and manure conveyor belts.

Main components

Fully automatic cleaning robot

The basic parameters of this product are: length 1400 mm, width 600 mm, height 2400-3200 mm, battery 24V DC, walking power is brushless DC motor, the support frame structure is 2-layer folding and 1-layer lifting, the support arm structure is two-stage two-dimensional adjustment, and the connecting pipes are stainless steel; the functional parameters include main frame height adjustable from 400mm to 760mm, main frame left and right adjustment of 400mm, wingspan 700mm to 1300mm, nozzle is 1 fixed + 8 adjustable, rinsing angle is 360 degrees adjustable, and walking speed is adjusted by a knob.

ScreenShot2026-01-07100637371

High-pressure Cleaning Machine

The high-pressure washer is configured with one 30KW variable frequency motor, one 30KW variable frequency starter cabinet, one 380V voltage unit, one stainless steel bag filter, one 1480r/min speed unit, one 345 kg weight unit, and one 50HZ rated frequency unit; its standard accessories include one 2m 10 square millimeter cable, one 2m return pipe, and one 2m air inlet pipe with filter.

Pipe Rolling Machine

The pipe rolling mill is equipped with a coil transport vehicle model ZH-100. The interface material and nozzle material are both copper. The P placement method is ground installation. The voltage is 24V DC. The product size is 70cm×82cm×100cm, the weight is 82KG, the connecting fittings are stainless steel, and a 100-meter high-pressure rubber hose is also provided.

Main functions

Lifting function

The position of the high-pressure nozzle can be adjusted freely according to the height of the cage layer to ensure cleaning effectiveness.

Intelligent control

We use a wireless remote control system and automatic control technology to precisely control the robot's movements such as walking, cleaning, starting and stopping.

Independent walking

The robot can walk autonomously inside the shed and adjust its walking speed according to actual needs.

Cleaning function

This is the core function of the sixth-generation robot. Our robot can not only perform shed cleaning, but also clean multi-layer cages.

Core advantages

01.

Save water and reduce energy consumption

Equipped with precise flow control and circulating spray technology, it adjusts the water volume as needed, avoiding the flooding of traditional flushing, and saving more than 50% of water compared to manual cleaning; at the same time, it can be adapted to the solid-liquid separation process of feces and sewage, reducing sewage discharge and lowering the cost of subsequent environmental treatment.

02.

Save manpower, reduce costs, and improve efficiency

With just one operator, the robot can autonomously clean the floors, crevices, and passageways of the enclosures by setting a pre-defined cleaning path. One robot can replace 5-8 cleaning workers, significantly reducing labor input. It operates continuously around the clock, with a cleaning efficiency more than 3 times that of manual labor, promptly removing feces and preventing the accumulation of harmful gases such as ammonia.

03.

Improved corrosion resistance and disease prevention capabilities

The entire body is waterproof and corrosion resistant, and can withstand the acidic and alkaline environment of the farm. It integrates cleaning and disinfection, and can carry disinfectant for precise spraying, reducing the risk of human contact with pollutants, cutting off the transmission route of germs, and helping to build a biosecurity system for the farm.

04.

Highly adaptable to various usage scenarios

The cleaning mode can be flexibly adjusted to suit the different pen structures of different livestock species (pigs, poultry, cattle, etc.), easily dealing with complex scenarios such as slatted floors and confinement stalls, balancing cleaning depth and equipment durability.

Why choose us?

01.

Conscientious Enterprise

We take responsibility for every product, strictly adhere to industry standards, and have established long-term partnerships with large and medium-sized enterprises.

02.

Strict material selection

We focus on every detail and strictly adhere to industry production standards to produce high-quality products.

03.

Price advantage

We supply directly from the factory, eliminating middlemen and passing the savings on to every customer. There are no middlemen taking a cut.

04.

Experienced

The company boasts strong technical capabilities, advanced equipment, rich experience, and sophisticated construction techniques, enabling it to flexibly respond to various on-site emergencies.
